Order no.: 0161440

EDL-25

P2000

Order no.: 0161440

EDL-25

PA ceiling speaker

100 V transmission technology via audio transformer with power taps 6/3/1.5 W
Type 130 full range speaker with dual cone
Plastic housing with protective metal grille
ABS plastic material, self-extinguishing according to UL 94V-0
For a ceiling thickness from 10 to 40 mm

Manufacturer information:

MONACOR INTERNATIONAL GmbH & Co. KG
Konsul-Smidt-Str. 68
28217 Bremen
Germany
info@monacor.com

continue

About

PA ceiling speaker

100 V transmission technology via audio transformer with power taps 6/3/1.5 W
Type 130 full range speaker with dual cone
Plastic housing with protective metal grille
ABS plastic material, self-extinguishing according to UL 94V-0
For a ceiling thickness from 10 to 40 mm

Manufacturer information:

MONACOR INTERNATIONAL GmbH & Co. KG
Konsul-Smidt-Str. 68
28217 Bremen
Germany
info@monacor.com

Specifications

Transmission technology	100 V
Frequency range	100-14,000 Hz
Power rating (RMS)	6/3/1.5 W
SPL	87 dB/W/m
Max. rated SPL	94 dB
Mounting cutout	Ø 165 mm
Mounting depth	60 mm
Dimensions	Ø 205 mm x 70 mm
Outside diameter	Ø 205 mm
Width	Ø 205 mm
Height	Ø 205 mm
Depth	70 mm
Colour	white
Admiss. ambient temp.	0-40 °C
Weight	0.724 kg
Packing unit	1
Type of speaker	130
Packaging dimensions (W x H x L)	0.205 x 0.07 x 0.205 m
Gross weight	0.832 kg
Net weight	0.724 kg

EAN code	4007754156690
Net weight	0.724 kg

Downloads

Accessories for EDL-25

Order no.: 0111340

JYSTY-2208

Signal line, type J-Y(St)Y, 4 x 0.5 mm2, 100 m

Intended use:
signal, 100 V PA, alarm, communication

Cable specification:
J-Y(ST)Y

Length:
100 m

Order no.: 0111340

JYSTY-2208

Signal line, type J-Y(St)Y, 4 x 0.5 mm2, 100 m
