Order no.: 0120610

LP-100-8

Order no.: 0120610

LP-100-8

L-pad attenuator
  • Level control for speakers
  • Mono version
  • With front panel and knob
Manufacturer information:
MONACOR INTERNATIONAL GmbH & Co. KG
Konsul-Smidt-Str. 68
28217 Bremen
Germany
info@monacor.com
continue

About

L-pad attenuator
  • Level control for speakers
  • Mono version
  • With front panel and knob
Manufacturer information:
MONACOR INTERNATIONAL GmbH & Co. KG
Konsul-Smidt-Str. 68
28217 Bremen
Germany
info@monacor.com

Specifications

Impedance 8 Ω ± 25%
Channels mono
Attenuation 0 dB to ∞ dB
Attenuation direction counterclockwise
Turning angle 300° ± 5°
Power rating 15 W MAX
Admiss. ambient temp. 0-40 °C
Weight 54 g
EAN code 4007754011050
Net weight 0.054 kg
