Order no.: 0161370

NR-40KS

P1970

P1330

P1240

P460

Order no.: 0161370

NR-40KS

Weatherproof horn speaker

16 Ω speaker system
IP66 tested, protected against powerful water jets
Suitable for general indoor and outdoor applications
Robust plastic housing
Mounting bracket and screws made of stainless steel

Manufacturer information:

MONACOR INTERNATIONAL GmbH & Co. KG
Konsul-Smidt-Str. 68
28217 Bremen
Germany
info@monacor.com

continue

About

Weatherproof horn speaker

16 Ω speaker system
IP66 tested, protected against powerful water jets
Suitable for general indoor and outdoor applications
Robust plastic housing
Mounting bracket and screws made of stainless steel

Manufacturer information:

MONACOR INTERNATIONAL GmbH & Co. KG
Konsul-Smidt-Str. 68
28217 Bremen
Germany
info@monacor.com

Specifications

Active/passive	passive
Transmission technology	cable
Total power rating	60 W
Power rating (RMS)	40 W
Impedance	16 Ω
Frequency range	180-7,000 Hz
Number of speakers	1
SPL	113 dB/W/m
Radiation angle/beam angle	H: 100°/V: 45°
Radiation angle, horizontal	100°
Radiation angle, vertical	45°
Housing material	plastic
Colour	light grey
Mounting device	stainless steel mounting bracket
Protection class	IP66
Admiss. ambient temp.	-20 °C to +50 °C
Dimensions	400 x 200 x 385 mm
Width	400 mm
Height	200 mm
Depth	385 mm
Weight	3 kg
Inputs	cable connection
Replacement voice coil	IT-40/VC
Other features	weatherproof
Packaging dimensions (W x H x L)	0.22 x 0.41 x 0.42 m
Gross weight	4.06 kg
Net weight	3.02 kg

EAN code	4007754154672
Net weight	3.02 kg

Downloads

Accessories for NR-40KS

Order no.: 0163360

ITH-300

Pole mount kit for horn speakers or cameras, V2A

Description:
pole mount

Type:
V2A

Colour:
stainless steel

Order no.: 0163360

ITH-300

Pole mount kit for horn speakers or cameras, V2A

Order no.: 0111340

JYSTY-2208

Signal line, type J-Y(St)Y, 4 x 0.5 mm2, 100 m

Intended use:
signal, 100 V PA, alarm, communication

Cable specification:
J-Y(ST)Y

Length:
100 m

Order no.: 0111340

JYSTY-2208

Signal line, type J-Y(St)Y, 4 x 0.5 mm2, 100 m
